STL100+STL200 series
STL134 LED
IP66, Class I. Class II on request. IK07. Marine-grade, die-cast aluminium alloy. 5CE superior corrosion protection including PCS hardware. Polycarbonate main lens. Silicone rubber gasket. Luminaire is factory-sealed and does not need to be opened during installation. Integral EC electronic converter. Advanced thermal management protects LEDs while optimising lumens output. Two cable entries. Pre-installation blockout is recommended for mounting in concrete, available on request.
Colours
RAL9004 Signal black
RAL9006 White aluminium
RAL9007 Grey aluminium
RAL7016 Anthracite grey
RAL9016 Traffic white
Material
| Body | Marine-grade die-cast aluminium alloy |
| Fasteners | PCS Polymer Coated Stainless Steel Hardware |
| Gasket | Silicone rubber gasket |
| Impact Protection | IK07 |
| Ingress Protection | IP66 |
| Finish | Powdercoat finish in RAL 9004, RAL 9006, RAL 9007 and RAL 9016 |
| Corrosion Protection | 5CE |
Electrical
| Ballast / Driver | Integral EC electronic converter |
| Cable | Two cable entries |
| Power Factor | > 0.9 |
| Power Supply | 220-240V / 50-60 Hz |
| Surge Protection | 1-2/2 kV |
Additional Information
| Lifetime | Ta=25° L80B10 > 54000h |
| Energy efficiency class | C (Light source) |
- - - -
